Typical Operating Wavelength:1940nm
Core Numerical Aperture:0.1±0.01
Core Diameter:25.0±1.0
Cladding Attenuation(dB/m@793nm):4.5±0.5
Cladding Absorption(dB/km@860nm):≤15.0
Changjin Photonics' double-clad CJTDF-25/400 thulium-doped fiber is a new product specially developed for 2-micron requirements. It features high polarization extinction ratio, high doping concentration, and high efficiency, meeting the needs of 2-micron high-power applications. The following is a detailed introduction:
Design Features
More Uniform Doping: The efficiency of thulium-doped fiber largely depends on doping uniformity, and high doping uniformity helps achieve high-efficiency conversion.
Higher Doping Concentration: Higher absorption is beneficial for achieving high gain in a shorter length, helping to prevent reabsorption effects and realize high-efficiency conversion.
Higher Birefringence: By designing the position of boron rods and increasing their concentration, a high polarization extinction ratio of the thulium-doped fiber is achieved.
Material Optimization
Optimized Material Composition: Through careful optimization of the fiber material composition, the fiber's resistance to photodarkening effect is improved, and the service life of the fiber is extended.
Optimized Coating Material: The selection and optimization of coating materials play an important role in protecting the fiber and improving its reliability. High-performance coating materials are adopted to effectively prevent the fiber from being affected by the external environment and ensure its stable operation in harsh industrial environments.
Performance Advantages
Higher Conversion Efficiency: Based on the above design features and material optimization, the fiber can achieve higher conversion efficiency.
Longer Service Life Under High Power: Under high-power operating conditions, the fiber has a longer service life, which reduces maintenance costs and replacement frequency, and improves production continuity and economy.
Type |
CJTDF-25/400-PM |
||
Optical
|
Operating Wavelength |
nm |
1600-2100 |
Core NA |
- |
0.1±0.01 |
|
CladdingNA |
- |
≥0.46 |
|
Cladding Attenuation@860nm |
dB/m |
4.5±0.5 |
|
Cladding Absorption@793nm |
dB/km |
≤15.0 |
|
Birefringence |
10-4 |
3.0±0.5 |
|
Geometrical&Mechanical |
Core Diameter |
μm |
25.0±1.0 |
Cladding Diameter |
μm |
400.0±5.0 |
|
Cladding Geometry |
- |
Circular |
|
Outer Coating Diameter |
μm |
550.0±10.0 |
|
Coating Material |
- |
low refractive index coating |
|
Matrix Material |
- |
silica |
|
Proof Test |
kpsi |
≥100 |
