Type
Parameter

CJYDF-10/125-PM

CJYDF-20/400-PM

CJYDF-25/250-PM

CJYDF-25/400-PM

CJYDF-30/250-PM

Optical

Operating Wavelength

nm

1060-1115

1030-1100

1030-1100

1030-1100

1030-1100

Core NA

-

0.080±0.005

0.065±0.005

0.065±0.005

0.065±0.005

0.060±0.005

Cladding NA

-

≥0.46

≥0.46

≥0.46

≥0.46

≥0.46

Cladding Absorption@915nm

dB/m

2.0±0.3

0.50±0.05

2.3±0.3

0.60±0.10

2.4±0.3

Core Attenuation@1200nm

dB/km

≤15.0

≤15.0

≤15.0

≤15.0

≤15.0

Cladding Attenuation@1095nm

dB/km

≤15.0

≤15.0

≤15.0

≤15.0

≤15.0

Birefringence

10^-4

3.0±0.5

3.5±0.5

≥2.0

3.5±1.0

3.0±1.0

Geometrical&Mechanical

Core Diameter

μm

11.5±1.0

20.0±1.5

25.0±2.0

25.0±2.0

30.0±2.0

Cladding Diameter

μm

125.0±5.0

405.0±5.0

250.0±10.0

400.0±10.0

250.0±10.0

Cladding Geometry

-

Circular,

Panda Circle

Circular,

Panda Circle

Circular,

Panda Circle

Circular,

Panda Circle

Circular,

Panda Circle

Coating Diameter

μm

245.0±15.0

550.0±15.0

395.0±15.0

550.0±15.0

395.0±15.0

Coating Material

-

low refractive index coating

low refractive index coating

low refractive index coating

low refractive index coating

low refractive index coating

Matrix Material

-

silica

silica

silica

silica

silica

Proof Test

kpsi

≥100

≥100

≥100

≥100

≥100
