● Series concentration doping,optimized for L-band amplifiers
|
● L-band single channel/multi-channel fiber amplifier |
|
Type |
CJEDF-M-30 |
CJEDF-M-37 |
CJEDF-M80-30 |
||
|
Optical
|
Operating Wavelength |
nm |
L-band |
L-band |
L-band |
|
Cut-off Wavelength |
nm |
≤1230 |
≤1230 |
≤1230 |
|
|
Core NA |
- |
0.26±0.02 |
0.26±0.02 |
0.26±0.02 |
|
|
Backgrouund Loss@1200nm |
dB/km |
≤10.0 |
≤10.0 |
≤10.0 |
|
|
Core Absorption@1530nm |
dB/m |
30.0±3.0 |
37.0±3.0 |
30.0±3.0 |
|
|
Mode-field Diameter@1550nm |
µm |
4.9±0.7 |
5.0±0.7 |
4.9±0.7 |
|
|
Geometrical&Mechanical |
Cladding Diameter |
µm |
125.0±1.0 |
125.0±1.0 |
80.0±1.0 |
|
Coating Diameter |
µm |
245.0±5.0 |
245.0±5.0 |
165.0±2.0 |
|
|
Core-Cladding Concentricity Error |
µm |
≤0.3 |
≤0.3 |
≤0.3 |
|
|
Coating Material |
- |
Circular |
Circular |
Circular |
|
|
Coating Material |
- |
high refractive index coating |
high refractive index coating |
high refractive index coating |
|
|
Matrix Material |
- |
silica |
silica |
silica |
|
|
Proof Test |
kpsi |
≥200 |
≥200 |
≥200 |
|
