● High concentration doping reduces nonlinear effects |
● Fiber amplifier |
|
Type |
CJEDF-M-50 |
CJEDF-M-80 |
CJEDF-M-100 |
CJEDF-M-150 |
||
|
Optical
|
Cut-off Wavelength |
nm |
≤1300 |
≤1300 |
≤1400 |
≤1500 |
|
Core NA |
- |
0.26±0.02 |
0.26±0.02 |
0.26±0.02 |
0.26±0.02 |
|
|
Backgrouund Loss@1200nm |
dB/km |
≤15.0 |
≤15.0 |
≤15.0 |
≤15.0 |
|
|
Core Absorption@1530nm |
dB/m |
50.0±10.0 |
80.0±20.0 |
100.0±20.0 |
150.0±30.0 |
|
|
Mode-field Diameter@1550nm |
µm |
5.0±0.7 |
5.0±0.7 |
5.0±0.7 |
5.0±0.7 |
|
|
Geometrical&Mechanical |
Cladding Diameter |
µm |
125.0±1.0 |
125.0±1.0 |
125.0±1.0 |
125.0±1.0 |
|
Coating Diameter |
µm |
245.0±5.0 |
245.0±5.0 |
245.0±5.0 |
245.0±5.0 |
|
|
Core-Cladding Concentricity Error |
µm |
≤0.3 |
≤0.3 |
≤0.3 |
≤0.3 |
|
|
Cladding Geometry |
- |
Circular |
Circular |
Circular |
Circular |
|
|
Coating Material |
- |
high refractive index coating |
high refractive index coating |
high refractive index coating |
high refractive index coating |
|
|
Matrix Material |
- |
silica |
silica |
silica |
silica |
|
|
Proof Test |
kpsi |
≥200 |
≥200 |
≥200 |
≥200 |
|
