Er and Yb Co-Doped Fiber

Er and Yb Co-Doped Fiber is mainly used in high-power telecommunications/CATV fiber amplifiers, laser ranging, LiDAR, and human eye safety lasers. This fiber has low fusion loss and high optical to optical conversion efficiency. A higher absorption coefficient ensures output power and lower cost. Based on the mature preparation process, optical fibers can regulate the absorption coefficient and gain spectrum, with good consistency.

Feedback
Download

Products Detail

Product Features

● Series concentration doping,suitable for fiberamplifiers with different application requirements
● High consistency and stable performance
● Acceptable customization

Application Area

● Fiber amplifier
● Fiber laser
● LiDAR
● Laser ranging

Type Parameter			CJEYDF-SM-6/125	CJEYDF-SM-6/125H	CJEYDF-SM-10/125	CJEYDF-SM-10/125H	CJEYDF-SM-12/125H
Optical	Operating Wavelength	nm	1530-1625	1530-1625	1530-1625	1530-1625	1530-1625
	Core NA	-	0.2±0.02	0.2±0.02	0.12±0.02	0.12±0.02	0.12±0.02
	CladdingNA	-	≥0.46	≥0.46	≥0.46	≥0.46	≥0.46
	Cladding Attenuation@1095nm	dB/km	≤30	≤30	≤30	≤30	≤30
	CladdingAbsorption@915nm	dB/m	0.75±0.25	1.0±0.25	3.5±1.0	3.0±0.5	3.5±1.0
	Core Absorption@1535nm	dB/m	30.0±10.0	60.0±15.0	40.0±15.0	70.0±15.0	70.0±15.0
Geometrical&Mechanical	Core Diameter	μm	6.0±0.5	6.0±0.5	10.0±1.0	10.0±1.0	12.0±1.5
	Inner Cladding Diameter	μm	125.0±3.0	125.0±3.0	125.0±3.0	125.0±3.0	125.0±3.0
	Coating Diameter	μm	245.0±15.0	245.0±15.0	245.0±15.0	245.0±15.0	245.0±15.0
	Inner Cladding Geometry	-	Octagon	Octagon	Octagon	Octagon	Octagon
	Outer Cladding Material	-	low refractive index coating	low refractive index coating	low refractive index coating	low refractive index coating	low refractive index coating
	Matrix Material	-	silica	silica	silica	silica	silica
	Proof Test	kpsi	≥100	≥100	≥100	≥100	≥100
