The CJ Photonics 1.5μm PM Passive Matching Fiber is matched with PM Er and Yb Co-Doped Fiber to achieve high matching performance, reduce fusion losses, and ensure the high-performance output of Polarization Maintaining Er and Yb codoped fiber in system applications.
|
● Better fiber optic reliability |
● Eye safety(1.5μm)fiber laser ● Laser ranging,LiDAR |
|
Type |
CJGDF-10/130 |
CJGDF-30/250 |
CJGDF-14/250 |
CJGDF-20/400 |
CJGDF-30/600 |
CJGDF-15/50/250-070 |
||
|
Optical
|
Operating Wavelength |
nm |
850-1115 |
850-1115 |
850-1115 |
850-1115 |
850-1115 |
800 - 2100 |
|
Core NA |
- |
0.075±0.005 |
0.062±0.005 |
0.070±0.005 |
0.065±0.005 |
0.065±0.005 |
0.070 ± 0.005 |
|
|
Cladding NA |
- |
≥0.46 |
≥0.46 |
≥0.46 |
≥0.46 |
≥0.46 |
≥ 0.46 |
|
|
Core Attenuation@1200nm |
dB/km |
≤20.0 |
≤20.0 |
≤15.0 |
≤15.0 |
≤20.0 |
≤ 15.0 |
|
|
Cladding Attenuation@1095nm |
dB/km |
≤15.0 |
≤15.0 |
≤15.0 |
≤15.0 |
≤20.0 |
≤ 15.0 |
|
|
Geometrical&Mechanical |
Core Diameter |
μm |
11.0±1.0 |
30.0±2.0 |
14.0±1.0 |
20.0±1.5 |
30.0±3.0 |
15.5 ± 1.0 |
|
Cladding Diameter |
μm |
130.0±5.0 |
250.0±5.0 |
250.0±10.0 |
400.0±10.0 |
600.0±5.0 |
250.0 ± 5.0 |
|
|
Core-Cladding Concentricity Eror |
μm |
≤1.0 |
≤1.5 |
≤1.0 |
≤1.5 |
≤2.0 |
≤ 2.0 |
|
|
Coating Diameter |
μm |
245.0±10.0 |
395.0±15.0 |
395.0±15.0 |
550.0±15.0 |
750.0±20.0 |
400.0 ± 10.0 |
|
|
Coating Material |
- |
low refractive index coating |
low refractive index coating |
low refractive index coating |
low refractive index coating |
low refractive index coating |
low refractive index coating |
|
|
Matrix Material |
- |
silica |
silica |
silica |
silica |
silica |
silica |
|
|
Proof Test |
kpsi |
≥100 |
≥100 |
≥100 |
≥100 |
≥100 |
≥ 100 |
|
Product Features
Application Area
