The CJ Photonics 2μm PM Passive Matching Fiber is designed specifically for high-power 2μm narrow-linewidth and single-frequency fiber lasers and amplifiers, ensuring high-performance output of PM thulium-doped fibers in system applications.
|
● Low splicing attenuation, excellent mode control
|
● 2μm narrow-linewidth fiber lasers |
|
Type |
CJGDF-15/250-PM |
CJGDF-25/400-PM |
||
|
Optical
|
Operating Wavelength |
nm |
1900-2100 |
1900-2100 |
|
Core NA |
- |
0.10±0.02 |
0.11±0.01 |
|
|
Cladding NA |
- |
≥0.46 |
≥0.46 |
|
|
Birefringence |
10-4 |
3.0±0.5 |
≥3.0 |
|
|
Geometrical&Mechanical |
Core Diameter |
μm |
15.0±1.0 |
25.0±2.0 |
|
Cladding Diameter |
μm |
250.0±10.0 |
400.0±10.0 |
|
|
Cladding Geometry |
- |
Circular, Panda Circle |
Circular, Panda Circle |
|
|
Outer Coating Diameter |
μm |
395.0±15.0 |
550.0±15.0 |
|
|
Coating Material |
- |
low refractive index coating |
low refractive index coating |
|
|
Matrix Material |
- |
silica |
silica |
|
|
Proof Test |
kpsi |
≥100 |
≥100 |
|
