Pure Silicon Core Multimode Energy Transmission Fiber

The Pure Silicon Core Multimode Energy Transmission Fiber of CJ Photonics is specially developed and designed for QBH transmission optical cables, capable of low loss transmission of high-energy lasers.

Feedback
Download

Products Detail

Product Features

● Low loss
● Excellent geometric consistency and core/cladding concentricity
● Circular fiber core NA and size

Application Area

● High power multi-mode output QBH

Type Parameter			CJBD-50/70/360	CJBD-75/90/360	CJBD-100/120/360	CJBD-150/172/360	CJBD-150/180/360
Optical	Operating Wavelength	nm	800-2100	800-2100	800-2100	800-2100	800-2100
	Core NA	-	0.22±0.02	0.22±0.02	0.22±0.02	0.22±0.02	0.15±0.02
	Inner Cladding NA	-	≥ 0.46	≥ 0.46	≥ 0.46	≥ 0.46	≥ 0.46
Geometrical&Mechanical	Core Diameter	μm	50.0±2.0	75.0±3.0	100.0±2.0	150.0±10.0	150.0±3.0
	First Layer Diameter	μm	70.0±2.0	90.0±5.0	120.0±2.0	172.5±2.0	180.0±3.0
	Second Layer Diameter	μm	360.0±3.0	360.0±7.0	360.0±3.0	360.0±3.0	360.0±3.0
	Cladding Diameter	μm	535.0±15.0	535.0±15.0	535.0±15.0	535.0±15.0	535.0±15.0
	Coating Material	-	low refractive index coating	low refractive index coating	low refractive index coating	low refractive index coating	low refractive index coating
	Bending Radius(short time)	mm	≥ 18	-	≥ 18	-	-
	Bending Radius(long time)	mm	≥ 54	≥ 54	≥ 54	≥ 54	≥ 54
	Proof Test	kpsi	≥100	≥100	≥100	≥100	≥100
