The Multi Cladding Energy Transmission Fiber of CJ Photonics is specially developed and designed for outputting point ring shaped light spots, providing a solution for multiple energy forms of fiber laser output.
|
● Excellent multi cladding structure |
● Dot ring spot output
|
|
Type |
CJMCF-14/40/100/120/360 |
CJMCF-34/48/100/120/360 |
CJMCF-50/70/150/172/360 |
CJMCF-100/120/300/360/460 |
||
|
Optical
|
Operating Wavelength |
nm |
800-2100 |
800-2100 |
800-2100 |
800-2100 |
|
Core NA |
- |
0.070±0.010 |
0.22±0.02 |
0.22±0.02 |
0.22±0.02 |
|
|
NA of the second layer cladding |
- |
0.22±0.02 |
0.22±0.02 |
0.22±0.02 |
0.22±0.02 |
|
|
NA of the fifth cladding |
- |
≥0.46 |
≥0.46 |
≥0.46 |
≥0.46 |
|
|
Geometrical&Mechanical |
Core Diameter |
μm |
14.0±0.5 |
34.0±2.0 |
50.0±2.0 |
100.0±2.0 |
|
Diameter of the first cladding |
μm |
40.0±2.0 |
48.0±3.0 |
70.0±3.0 |
120.0±3.0 |
|
|
Diameter of the second cladding |
μm |
100.0±2.0 |
100.0±4.0 |
150.0±4.0 |
300.0±4.0 |
|
|
Diameter of the third cladding |
μm |
120.0±4.0 |
120.0±4.0 |
172.0±4.0 |
360.0±4.0 |
|
|
Diameter of the fourth cladding |
μm |
360.0±5.0 |
360.0±5.0 |
360.0±5.0 |
460.0±5.0 |
|
|
Diameter of the fifth cladding |
μm |
455.0±5.0 |
455.0±10.0 |
455.0±15.0 |
540.0±15.0 |
|
|
Coating Diameter |
μm |
540±14.0 |
540±15.0 |
540±20.0 |
650±20.0 |
|
|
Inner Coating Material |
- |
low refractive index coating |
low refractive index coating |
low refractive index coating |
low refractive index coating |
|
|
Matrix Material |
- |
silica |
silica |
silica |
silica |
|
|
Proof Test |
kpsi |
≥100 |
≥100 |
≥100 |
≥100 |
|
