Microstructured Passive Fiber

CJ Photonics continuous-series double-clad Yb-doped photonic crystal fiber is designed for high-power ultrafast lasers and high-pulse-energy fiber amplifiers. Featuring a large mode area, single-mode output, high beam quality, high absorption coefficient, and high stability, this fiber is suitable for ultrafast lasers with hundreds of watts of power, and finds applications in semiconductor manufacturing, material processing, imaging, scientific research, and other fields.

Feedback
Download

Products Detail

Product Features

● Large mode area
● High beam quality
● High absorption coefficient
● Customization available

Application Area

● Ultrafast laser
● High-pulse-energy fiber amplifier
● Semiconductor
● Material processing and imaging

Type Parameter			CJ-SDPCF-40200-PM
Optical	Operating Wavelength	nm	1030-1100
	Core NA	-	0.03
	Inner Cladding NA	-	≥0.50
	Cladding absorption @915nm	dB/m	-
	Core attenuation @1200nm	dB/km	≤20.0
	Cladding attenuation @1095nm	dB/km	≤20.0
Geometrical&Mechanical	Core diameter	μm	40.0±2.0
	Cladding diameter (edge-to-edge)	μm	450.0±20.0
	Cladding shape	-	Quasi-circular
	Coating diameter	μm	540.0±30.0
	Coating material	-	high refractive index coating
	Matrix material	-	silica
