Type
Parameter

CJ-ROD-55

CJ-ROD-85

CJ-YDPCF-40/200-PM

CJ-YDPCF-15/135-PM

Optical

Operating Wavelength

nm

1030-1040

1030-1040

1030-1100

1030-1100

Core NA

-

-

-

0.03

0.055±0.01

Inner Cladding NA

-

≥0.50

≥0.50

≥0.50

≥0.50

Cladding absorption @915nm

dB/m

5.0±0.5

5.0±0.5

3.0±0.50

2.80±0.50

Core attenuation @1200nm

dB/km

≤20.0

≤20.0

≤20.0

≤20.0

Cladding attenuation @1095nm

dB/km

≤20.0

≤20.0

≤20.0

≤20.0

Geometrical&Mechanical

Core diameter

μm

55.0±10.0

85.0±10.0

40.0±2.0

15.0±1.0

Cladding diameter (edge-to-edge)

μm

200.0±10.0

260.0±10.0

450.0±20.0

135.0±5.0

Cladding shape

-

Circular

Circular

Sub circular

Sub circular

Coating diameter

μm

-

-

540.0±20.0

345.0±20.0

Coating material

-

-

-

High refractive index coating

High refractive index coating

Matrix material

-

Quartz

Quartz

Quartz

Quartz
