The CJ high-phosphorus-doped Raman fiber is specifically designed for efficient Raman lasers and amplifiers operating in the 1.1–1.6 μm spectral range. Compared with germanium-doped fibers, the main advantage of phosphorus-doped fibers is a Raman shift value three times higher. This characteristic can significantly simplify the design of Raman fiber lasers and amplifiers.
|
● High Raman gain coefficient |
● Raman fiber amplifier |
|
Type |
CJPDF-SM-5/125 |
||
|
Optical
|
Core NA |
- |
0.20±0.02 |
|
Inner cladding NA |
- |
≥0.46 |
|
|
Mode-field Diameter@1550nm |
μm |
6.0±0.5 |
|
|
Cut-off Wavelength |
nm |
≤970 |
|
|
Typical dispersion @980nm |
ps/(km*nm) |
-60 |
|
|
Geometrical&Mechanical |
Core diameter |
μm |
5.0±0.5 |
|
Inner cladding diameter |
μm |
125.0±3.0 |
|
|
Core-cladding concentricity |
μm |
≤0.50 |
|
|
Coating diameter |
μm |
245.0±10.0 |
|
|
Coating material |
- |
high refractive index coating |
|
|
Screening strength |
kpsi |
≥100 |
|
